F6 Dual Fetal Monitor, 347mm x 330mm x 126mm

Manufacturer: EDAN USA
List Price: $5,229.99 EA
View All Specs
Manufacturer: EDAN USA
View All Specs
Product description:
F6 is a high end hospital grade monitor designed for multi-bed units with central station yet simple enough for private practice, it offers the most advanced integrated monitoring for the delivery room in big hospital; private obstetrician's office; antepartum clinic. F6 are designed for use in moving situation covers the entire continuum of antepartum and intrapartum applications.
  • Basic parameters: FHR, TOCO, Event Mark, AFM
  • Optional dual FHR monitoring
  • Optional internal parameters: IUP/DECG
  • 24-hour Waveforms playback
  • Optional built-in wireless module
  • 150/152mm Wide paper printing
  • Support American/International standard
  • 1,2,3cm/min Real-time printing speeds
  • Quick printing for stored waveform
  • Lithium battery for 4hrs continuous work ing
  • 10.2in High resolution color fold ing up LCD screen
  • Probe rack and wall mounting rack
  • Handle for easy carry
  • Optional fetal stimulators
  • Multi-crystal pulse wave Doppler waterproof transducer for FHR detection
  • Signals overlap verification
  • Includes 2) FHR Probes, (1) TOCO Probe, (1) Event Marker, (3) Belts, (1) Ultrasound Gel (CE Mark, 250g), (3) Recording Paper (90mm x 152mm x 150p, U.S. Standard), (2) T1.6AL Fuse, 1) Power Cord (USA Standard), (1) User Manual, (1) Quick Reference, (1) Guide to Fetal Heart Monitoring, (1) Insight Software CD, (1) Insight Software User Manual, (1) Insight Connection Cable, (1) Ethernet Cable, (1) RS232 to USB Adapter and Driver CD (HL 340), (1) Ground Cable, (1) Screwdriver
You are unable to select more than your available quota at this time. Please contact your administrator for assistance.
Total Items Selected
Total Items Selected
F6 Dual Fetal Monitor, 347mm x 330mm x 126mm
Product # 660313
IUP Non-linear Error ±3mmHg
Printing Recording Paper 150/152mm, Z-fold, Thermosensitive, American/International Standard
IUP Pressure Range 0 to 100mmHg
Printing Recorder 1,2,3/cm/min. Real Printing Speed. Fast Print Speed (Stored Traces) Up to 25mm/sec
TOCO Range 0 to 100% Relative
Ultrasound Technique Ultrasound Pulse Doppler with Correlation
DECG Accuracy ±1bpm
TOCO Resolution 0.01
Resolution 800 x 480
IUP Zero Mode Auto/Manual
Display Type TFT-LCD
TOCO Non-linear Error ≤±10%
DECG Technique Peak - Peak Detection Technique
DECG Input Impedance >10M (Differential), >20M (Common Mode)
IUP Resolution 0.01
Battery Type 14.8V Rechargeable Lithium-ion Battery
Display Size 10.2in
Battery Life 2 to 4 hours
DECG Resolution 1bpm
Auto Fetal Movement Technique Pulsed Doppler Ultrasound
Auto Fetal Resolution Range 0.01
Dimensions 347mm x 330mm x 126mm
Ultrasound Resolution 1bpm
Weight 6kg
Ultrasound FHR Range 50 to 240bpm
Communication Port DB9 Network Interface, RJ45 Interface
Ultrasound Accuracy ±2bpm
Marking Manual Fetal Movement Mark
DECG FHR Range 30 to 240bpm
Ultrasound Frequency 1MHz+10%
TOCO Zero mode Auto/Manual
Auto Fetal Movement Range 0 to 100%
Ultrasound Pulse Repetition Rate 2KHz
